Yamaha MGX12V 18-Channel Digital Mixing Console with Video

Powering creativity with a multifunctional workflow

While the Yamaha MGX12V is certainly a powerful digital mixer, it also serves as a capable multifunctional creative hub. Its optimized integration capabilities, which include flexible routing and dual Main and Sub USB ports, equip you with a 18-in, 18-out USB audio interface, plus 2-track recording and playback on the Sub port. Bluetooth connectivity enables smooth wireless audio integration for performances, streaming, and studio sessions, while eight customizable pads allow you to trigger sound effects or user-defined functions in real time. Moreover, with the ability to record up to 16 tracks and play back two directly from a microSD card, the MGX12V empowers you to capture professional-quality audio anywhere, whether you’re backing up a mobile session or delivering polished playback in a live venue.

Smart tools that work as fast as you do

Navigating the MGX12V is an incredibly intuitive affair, thanks to its streamlined physical controls and an easy-to-use 4.3-inch touchscreen. The mixer’s 12 non-motorized faders facilitate precise control over audio levels, bolstered by dedicated Send knobs, a feature-packed touch LCD, four customizable knobs, and a responsive Touch and Turn knob. You’ll find the MGX12V’s intelligent assistive tools — featuring Smart Gain and Clip Safe — especially valuable. Moreover, the Total FX suite, which includes a Ducker and a Multi-Band Compressor, certifies consistently polished results whether you’re onstage, in the studio, or in the midst of a livestream. You also get lightning-fast Scene Recall and an optional Simple Mode, enabling you to switch setups instantly and stay focused on what matters most: your creativity.

Unrivaled power for stunning audiovisual production

The Yamaha MGX12V comes equipped with advanced HDMI-USB capture and HDMI passthrough capabilities, facilitating seamless integration of high-definition video into your video production or streaming setup. With the MGX12V, you can craft a compact, unified system that manages PA and monitors audio while simultaneously supporting streaming and recording — exactly what you need to accommodate small-scale live events, hybrid concerts, podcasts, and full broadcast workflows. Simply put, this digital mixer delivers a level of audiovisual performance that inspires confidence, enabling audio and video to work together flawlessly. Boasting HDMI In and Thru, along with a robust USB-HDMI interface capable of handling up to 4K at 60 fps, 1440p at 120 fps, and 1080p at a stunning 240 fps, the MGX12V makes it easy to capture and pass through high-definition audio and video from cameras, gaming consoles, and other external devices, yielding content that always looks and sounds its best. Finally, lock-tight integration with Elgato and OBS Studio further enhances this digital mixer’s video capabilities.

Yamaha MGX12V Features:

• A 12-input digital mixer melding studio-quality sound with flexible routing, intuitive operation, and seamless video integration
• 12 non-motorized faders, a vivid 4.3-in. touchscreen, and 5 control knobs offer straightforward operation
• 4 premium-quality MGX mic preamps on Mic/Line combo inputs
• 4 Headphone outputs yield robust monitoring capabilities
• 12 mix inputs with mono and stereo channels, a dedicated Sound Pad, 2 FX channels, and robust Mix, FX, Cue, and Stereo buses
• 18-in/18-out USB audio interface, plus 2-track recording and playback on the Sub port
• Bluetooth audio input enables smooth wireless audio integration for performances, streaming, and studio sessions
• 8 customizable pads allow you to trigger sound FX or user-defined functions in real time
• Onboard 16-track recording to a microSD card with 2-ch. playback
• USB-HDMI audio/video interface with a capture function and real-time HDMI passthrough
• Refined DSP provides you pristine digital FX and latency-free monitoring
• Useful assistive features, comprising Auto Gain, Clip Safe, Simple/Standard mode, and Scene Recall
• Includes a practical cache of Steinberg production software and smooth Elgato and OBS Studio integration

Technical Specification

• Type: Digital Mixer
• Channels: 12
• Inputs - Mic Preamps: 4
• Inputs - Line: 4 x XLR-1/4" Combo, 4 x 1/4"
• Inputs - Other: 2 x Dual RCA Stereo
• Outputs - Main: 2 x XLR
• Outputs - Direct: 6 x 1/4" TRS
• Data I/O: 2 x HDMI
• Headphones: 4 x 1/4" TRS
• USB: 2 x USB-C
• Faders: 12
• Screen: 4.3" touchscreen
• Storage: microSD card slot
• Software: Cubase Al, WaveLab Cast LE, Basic FX Suite, and Steinberg Plus software bundle
• Power Source: 16V DC Power Supply
• Height: 3.8"
• Depth: 12.6"
• Width: 13.2"
• Weight: 9 lbs.

  What is the MGX12V mixer?
A: The MGX12V is a compact digital mixer with a built-in HDMI video interface, designed for audio + video production, streaming, and live events.

  How many channels does it have?
A:

• 4 mono (mic/line)
• 4 stereo channels
• FX returns + sound pad

  What makes MGX12V unique?
A:

• Built-in HDMI video capture + pass-through
• Combines mixer + audio interface + capture card

  Does MGX12V support video capture?
A: Yes. It includes:

• HDMI-to-USB capture
• Real-time HDMI pass-through

  Can I connect cameras or gaming consoles?
A: Yes, via HDMI input.

<
