BASSBOSS DiaMon PB MK3 12" Coaxial Powered Loudspeaker

The 2-Way BASSBOSS DiaMon PB MK3 made for mobile DJ setups and live sound (including outdoor installations), is one of the best 96kHZ DSP-driven 12-inch 1200W Active Powered Top Coaxial Loudspeaker Monitors nowadays.

You're looking for an edge. You like to be able to load in and load out alone. You need a system that will cover a large area. You need more sound from less space and less weight. Because smaller tops are easier to lift. Because you want more sound, not bigger speakers. Because you don't want the same boring speakers as everyone else. Because you think DJs deserve kick-ass monitors.

The DiaMon doesn't waste any energy or space trying to deliver the lows that the subs can handle perfectly well. Its power is concentrated on the very important job of delivering loud, clear mids and highs. Enough to keep up with several large subs. A high-efficiency 12" midrange/woofer with a 3" compression driver tweeter firing through the middle is loaded into a cabinet that's as small as possible, just big enough to hold the driver, the 1200W amp, and the DSP electronics.

Specification

• Loudspeaker Description: 2-Way Single 12" Self-Powered Direct Radiating Co-axial Point Source Mid-High
• Frequency Response (±3 dB): 80 – 18,000Hz (Full Range - Preset 1) +-3 dB
• Maximum Sustained Output: 123 dB SPL 1m half-space
• Max SPL (Peak): 126 dB SPL 1m half-space (Limited in full-range)
• Nominal Dispersion (H° x V°): 80 x 80 (Conical)
• Amplification: 1200 W Class D, 2 Channel
• Processing: Integrated comprehensive DSP. 96kHz sampling rate with 8 pushbutton presets. All presets include high pass filters, low pass filters, phase alignment, equalization and multi-stage limiting. Storage capacity for up to 100 presets
• Electrical Connector Amp: Neutrik powerCON True 1 TOP IP65 rated waterproof connectors
• Electrical Connector Mains: Standard US 3-pin grounding 120V electrical plug: NEMA 5-15 (Edison)
• Voltage Operating Range: 100-240V AC, 50-60Hz (Auto-sensing, auto switching universal supply)
• Current Draw 120V: 1.4 Amps (Nominal)
• Current Draw 240V: 0.7 Amp (Nominal)
• Signal Input Connector: XLR-F
• Signal Output Connector: XLR-M (direct pass-through only)
• Enclosure Type: 2-way active mid-high. Direct radiating sealed 12″ LF, co-axial horn-loaded HF
• Transducer Low Frequency: 1 x 12 in. diameter (300mm) neodymium motor woofer with 3 in. (76 mm) copper winding voice coil
• Transducer High Frequency: 1 x 3 in. (76mm) diameter diaphragm compression driver with 1.4" (35mm) exit through 80 degree conical wave guide machined from aluminum ploe piece in the center of the midrange driver
• Cabinet Construction: CNC machined 18 and 15mm Birch plywood with dado joinery. 1 x 35mm steel pole socket
• Exterior Finish: High-pressure, bonded polyurea coating. Rugged, waterproof. Textured black
• Grille: Perforated, powder-coated steel

  What is the BASSBOSS DiaMon MK3?
A: The DiaMon MK3 is a 2-way active 12” coaxial loudspeaker designed mainly for mid-high frequencies, delivering clear and powerful sound in a compact form.

  Is it good for vocals and DJ use?
A: Yes

• Excellent vocal clarity
• Smooth high-frequency response
• Ideal for DJ, live vocals, installs

  Can it be used without a subwoofer?
A: Yes, for:

• Small events
• Background music
• Cocktail setups

  Can it be mounted or installed?
A: Yes

• Pole mount (35mm socket)
• Wall/ceiling brackets available
• Can be used as a DJ monitor

  Who is this speaker best for?
A:

• Mobile DJs
• Clubs & bars
• Installations (restaurants, gyms, lounges)
• Event production companies

<
