Pioneer PLX-CRSS12 and DJM-S11 Package

KEY FEATURES

Tone-arm-free DVS control eliminates skipping in digital playback

No matter how hard you scratch, you'll never experience needle skipping when you use the PLX-CRSS12 in Digital Vinyl mode, thanks to the tone-arm-free system. The new MAGVEL CLAMP holds a record firmly in place when you touch it, enabling it to directly control the digital music file, giving you the true feeling of vinyl with no need to use the tone arm. When playing analog records, the experience will be just like using the popular PLX-1000 deck.

Feeling adjustment to suit your style

You can quickly adjust the record's "weight" with the dial on top of the MAGVEL CLAMP. This means you can effortlessly continue your performance without the hassle of changing slip mats or slip sheets.

Customizable torque level

It's easy to change the turntable rotation torque level in the utility settings to suit your preference. You can choose from "High" for quick startup when you press PLAY, "Low" for the traditional torque speed that many DJs are familiar with, and "Mid" for a balance between the two.

Adjustable stopping speed

Use the switch on the front of the deck to adjust the time it takes for the turntable to stop when you press STOP. The "Min" is sharp. The "Mid" uses a traditional stopping speed that's familiar to DJs. And the "Max" creates the longest stopping speed for a gradual and dramatic finish to a track or performance.

Performance Pads for accurate and rapid control

The PLX-CRSS12 inherits classic turntable layout elements, but a new addition is the 4 built-in MIDI-mappable Performance Pads which put your favorite features at your fingertips. They're right where you need them - just below the platter - so you can fire off Hot Cues and samples quicker than ever, which comes in handy even more if you're performing on a mixer that has no pads. There's native support for various pad modes (see below), and a dedicated button enables you to switch control from pads 1-4 to 5-8. The pads are MIDI mappable too, so you can assign them to other features.

OLED display for quick confirmation of track information

The built-in OLED display also helps you focus on the deck. You can keep an eye on the tempo range and key when Step Pitching and, when you connect the PLX-CRSS12 via USB to your PC/Mac running DJ software, you can reference BPM, key, deck number information. The display also gives you quick access to the utility settings - all of which reduces the need to break concentration and look at your laptop or mixer during a performance.

High-quality sound reproduction of analog records, evolved from the PLX-1000

Let your audience enjoy your music the way it was intended to be heard. The PLX-CRSS12 has been carefully built to improve on the sound quality of the PLX-1000 professional DJ turntable, which is highly acclaimed for its accurate sound reproduction.

Switching power supply

A switching power supply is used to eliminate transformer power supply vibration and flux leakage, and unwanted noise is suppressed, resulting in high-resolution sound quality.

High-mass die-cast zinc

As with the PLX-1000, the upper part of the chassis is made of high-mass die-cast zinc and the lower part is made of 8 mm thick resin to optimize the chassis structure and vibration-damping materials.

Machined gold-plated RCA terminals

The RCA terminals are made of machined gold-plated parts like those on the PLX-1000, and the phono signal is directly transmitted through a stable connection with the plug to reproduce the sound of analog records with high-quality audio.

Robust and elegant design in matte black color

The PLX-CRSS12 has a matte black color scheme, with special coatings applied to the tone arm and other metal parts, plus carefully crafted details that give it a robust and elegant appearance.

Serato DJ Pro and rekordbox compatibility

The PLX-CRSS12 is compatible with Serato DJ Pro and rekordbox. By connecting this unit to a PC/Mac with DJ software installed, and to a mixer that supports the DVS function of the respective DJ software, you can start playing in Digital Vinyl mode and use the Performance Pads.

OTHER FEATURES

Replaceable MAGVEL CLAMP

Additional clamps are available to buy if you want to take your own set on the road, or if you need to replace a clamp that's been lost. You can store the MAGVEL CLAMP neatly in a dedicated area on top of the deck.

Firmware Update Manager

You'll be automatically notified when firmware updates become available. You can download the Firmware Update Manager here.

AlphaTheta Care

Our extended product warranty service ensures longer and more reliable use of your products.

Specifications

Main Features

Accessories

• Platter
• Screws for platter
• Screwdriver
• MAGVEL CLAMP
• Slip mat
• Slip sheet
• Dust cover
• Balance weight
• Sub weight
• Headshell
• Shell weight
• Power cord
• Audio cable (with ground wire)
• USB cable
• Quick Start Guide
• Warranty (for some regions)*
• Precautions for Use
• *Only products in Europe. Products in North America and Japan include warranty information in the Precautions for Use.

Specifications

• Width: 17.83 in
• Height: 6.26 in
• Depth: 13.9 in
• Weight: 26.9 lb

Turntables

• Drive Method: Servo-type direct drive
• Platter: Aluminium, die-casting diameter: 332 mm
• Motor: 3-phase, brushless DC motor
• Braking System: Electronic brake
• Rotation Speed: 33¾ rpm, 45 rpm
• Rotation Adjustment Range: ±8, ±16, ±50 %
• Wow and Flutter: 0.15% or less WRMS (JIS WTD)
• Signal-to-Noise Ratio: 65 dB (DIN-B)
• Starting Torque: High: 0.45 Nm (4.5 kgfcm) or more
  Mid: 0.32 Nm (3.2 kgf cm)
  Low: 0.2 Nm (2.0 kgf cm)
• Start Time: 0.3 sec (at 33¾ rpm)
• Brake Time: Max: 3.5 seconds
  Mid: 1.0 seconds
  Min: 0.5 seconds or less

Tone Arm

• Arm Type: Universal type S-shape tone arm
  Gimbal-supported type bearing structure
  Static balance type
• Overhang: 0.59 in
• Effective Length: 9.06 in
• Tracking Error: Within 3°
• Height Adjustment Range: 0.24 in
• Stylus Pressure Variable Range: 0-4 g (1 scale 0.1 g)
• Cartridge Weight Single: 2.5-12 g (includes mounting materials)

Terminals

• USB: 1 USB C port
• Outputs: 1 PHONO(RCA)

Pioneer DJ DJM-S11

Battle Mixer W/ Touch Screen for Serato or rekordbox

The Pioneer DJ DJM-S11 is the Newest Battle Touch Screen DJ Mixer. It Takes Artists to the Next Level with Unique and Innovative Features. The Pioneer DJ DJM-S11 is a professional 2-channel, 4-deck battle mixer that Enhances elements from its popular predecessors, the DJM-S9 and DJM-909. It offers a host of new features helping DJs perform freely within Serato DJ Pro or rekordbox.

For Battle DJ's every Milli-Second is priceless and it becomes a priority to offer a Screen that will allow you to scratch and make mash-ups on the fly. The New 4.3-inch customizable touch display will deliver all the information needed to make a seamless mix on the spot. Browse tracks, check on playback positions and wave-forms, and dynamically change the music texture by moving their finger across the Touch FX screen. The Touch MIDI feature enables artists to trigger functions in the DJ software. Together, these new features allow users to stay focused and keep their eyes on the mixer during their performance.

The New Pioneer DJ DJM-S11 Deck 3/4 Control feature allows DJs to play up to four tracks at once, making the difference between an OK crowd reaction and a Great one. Additional decks appear on this touch screen DJ mixer's display with a selection of controls so they can browse and load tracks, adjust EQs, set loops, trigger Hot Cues and more.

With the Deck Move Feature, Serato DJ Pro Users can now move tracks from deck one to four, and deck two to three without a break in the music. This frees up the main decks and allows preparation time to drop in the next track. With the new Dual Deck Control, users can use one fader, knob or control vinyl to manipulate tracks loaded on decks 1&3 or 2&4 - this means you can scratch two tracks at once plus add effects, or adjust their volume simultaneously using this Serato DJ mixer.

New Features of the Pioneer DJ DJM-S11 touch screen DJ mixer vs the DJM-S9 Include the Serato DJ Mixer's redesigned Layout also delivers a more intuitive feel, new controls and improved sound performance. With the Performance Pads Now Being Larger and the Magvel Fader Pro strengthened, it will give you more stability when you're scratching or drumming samples. One of the most prominent new Pioneer DJ DJM-S11 features, Smooth Echo, allows users to automatically engage echo when moving the faders, or hit ting the trigger pads. Improved sound performance delivers clear, powerful audio-reflecting every performance nuance. The feature with the most requests is now available with this New Battle Serato DJ Mixer. It includes a built-in USB hub that enables users to directly connect with CDJs and the DDJ-XP2. This Feature that will make Rane Tweleve Users Very Happy.

• Scratch Bank: Rapidly Access Sounds from Serato DJ ProDJM-S11
• High-quality audio: Crystal-clear Sound, Faithfully Reflects Every Performance Nuance
• Improved Magvel Fader Pro: Feel Supported When Scratching
• 22 Built-in Effects Including New Beat FX: Add Texture to Tracks
• Direct USB Connections or Hub
• Plug and Play and MIDI Mapping: Use Serato DJ Pro or rekordbox for Free

Features:

• Enhanced design, larger pads, and low latency.
• 4.3-inch touch screen with high frame rate.
• 22 built-in effects including new Beat FX.
• Plug and play and MIDI mapping.
• World's first Deck 3/4 Control.
• Improved MAGVEL FADER PRO.
• Industry-first Smooth Echo.
• Direct USB connections.
• Scratch Bank.

Specification:

• Software: Serato DJ Pro or rekordbox
• Frequency Response: 20Hz to 20,000Hz (USB, LINE, MIC, AUX)
• S/N Ratio:
• 115dB (USB)
• 105 dB (LINE)
• 90 dB (PHONO)
• 80 dB (MIC)
• 90 dB (AUX)
• Total Harmonic Distortion
• 0.003%(USB)
• 0.005 % (LINE)
• Inputs:
• 2 Line (RCA)
• 2 Phono (RCA)
• 1 MIC (XLR & 1/4-inch TRS Jack)
• 1 AUX (RCA)
• Outputs:
• Master 2 XLR, 2 RCA
• Booth 1 1/4 Inch TRS Jack
• Headphones 1 1/4 Inch, 1 1/8 Inch
• USB HUB: Yes
• 2 Type A
• 2 Type B
• Power Supply: AC100V, 50Hz/60Hz
• Power Consumption: 30 Watts
• Dimensions: 10.51" x 17.8" x 4.25" Inches
• Weight: 11.46 lbs
• Accessories:
• Fader bumpers (A x 4, B x 2)
• Serato DJ Pro Expansion Pack voucher
• (Pitch 'n Time DJ)
• Certificate of Guarantee
• Quick Start Guide

What's Included:

• Fader bumpers (A x 4, B x 2)
• Serato DJ Pro Expansion Pack voucher
• (Pitch 'n Time DJ)
• Certificate of Guarantee
• Quick Start Guide
