Electro Voice ELX115

Description

The versatile ELX115 loudspeaker is a compact, powerful choice with real stage presence, for sound reinforcement and stage monitoring applications.

• MORE POWER, FULLER SOUND FOR LARGER ROOMS
• EVS-15K WOOFER
• 1.5-INCH DH-1K TITANIUM HF COMPRESSION DRIVER
• 50 HZ – 20 KHZ FREQUENCY RANGE
• 90° X 50° COVERAGE-PATTERN WAVEGUIDE
• 60° MONITOR ANGLE
• 134 DB MAX SPL
• POWER HANDLING: 400 W CONTINUOUS, 1600 W PEAK
• BRACED 15MM PLYWOOD ENCLOSURE
• POLE MOUNT OR STACK WITH LIVE X SUBWOOFERS
• BLACK TEXTURED FINISH
• Available Color Black
• Axial Sensitivity (SPL, 1 W @ 1 m) 95 dB
• Case Material 9-ply, 15mm Plywood, Internally Braced, with Textured Paint
• Connector Type Parallel Neutrik® NL4
• Coverage (Nominal -6 dB) H 90 °
• Coverage (Nominal -6 dB) V 50 °
• Crossover Frequency 17000 Hz
• Depth 382 mm
• Enclosure Material 9-ply plywood
• Family ELX
• Frequency Response (-10 dB) 50 - 20000 Hz
• Frequency Response (-3 dB) 75 - 18000 Hz
• Grill 18GA Steel with Black Powdercoat
• Height 708 mm
• HF Transducer DH-1K, 39mm (1.5") Titanium Diaphragm Compression Driver
• Internal Crossover Yes
• LF Transducer (1) EVS-15K, 381mm (15") Woofer
• Max. SPL/1m (calc) 134 dB
• Minimum Impedance 7.4 Ω
• Nominal Impedance (Passive) 8 Ω
• Powered or Passive Passive
• Recommended High-Pass Frequency 40 Hz
• Speaker Type Full-Range, mid-high, two-way
• System Power Handling (Continuous/Program/Peak) 400//1600 Watts
• Weight Net 21.9 kg
• Width 432 mm
• Woofer Size 15 inch
