Key Features

• 24-bit/192kHz resolution for professional recording and monitoring
• Hi-Speed USB circuitry for fastest connection, with class-leading round-trip latency of 2.59ms*
• Transparent Crystal™ preamps and ultra-pristine A/D converters for unsurpassed audio recording quality
• VU LED meters for dialing in the perfect level
• Flexible inputs: (2) XLR+¼" TRS combo with -10dB mic pad or ¼" instrument inputs
• Use any combination of TRS combo or ¼" instrument input on the two channels:(2) TRS, (2) instrument or (1) of each
• MIDI input/output for connecting virtually any external MIDI gear
• Stereo ¼" and RCA outs with direct mono/stereo switch
• (2) RCA assignable auxiliary outputs; ¼" headphone output with independent source and level controls
• Rugged metal chassis; large central control for easy volume adjustment
• USB/Direct knob for balancing between the input signal and the computer signal
• *Round trip latency is dependent on buffer settings, and computer hardware

Specifications

Minimum System Requirements

• macOS: 10.8 Class Compliant
• PC: Windows 7, Windows Driver
• Standard USB 2.0 or USB-C Port

Mic Inputs 1-2 (balanced XLR)

• FREQUENCY RESPONSE 20Hz - 20kHz (+/-0.1 dB)
• DYNAMIC RANGE 104dB (A-weighted)
• SIGNAL-TO-NOISE RATIO 104dB (+1.0dBu, A-weighted)
• THD+N 0.001% (1kHz, +0.8dBu, -1dBFS)
• PREAMP EIN -126dBu (150O, unweighted)
• MAX INPUT LEVEL +1.8dBu
• GAIN RANGE 60dB

Line Input 1-2 (balanced 1/4" TRS)

• FREQUENCY RESPONSE 20Hz - 20kHz (+/-0.1dB)
• SIGNAL-TO-NOISE RATIO 101dB (1kHz, +4dBu, A-weighted)
• THD+N 0.002% (1kHz, +19.7dBu, -1dBFS)
• MAX INPUT LEVEL +20.7dBu
• DYNAMIC RANGE 106dB (A-weighted)

Inst Input 1-2 (unbalanced 1/4" TS)

• FREQUENCY RESPONSE 20Hz - 20kHz (+/-0.1dB)
• DYNAMIC RANGE 106dB (A-weighted)
• SIGNAL-TO-NOISE RATIO 98dB (+4dBu, A-weighted)
• THD+N 0.001% (1kHz, +5.8dBu, -1dBFS)
• MAX INPUT LEVEL +6.8dBu
• INPUT IMPEDANCE ~1MO
• GAIN RANGE 24dB

Main TRS Outputs, 1/L & 2/R (balanced 1/4" TRS)

• FREQUENCY RESPONSE 20Hz - 20kHz (+/-0.1dB)
• DYNAMIC RANGE 109dB (A-weighted)
• THD+N 0.003% (1kHz, -1dBFS)
• MAX OUTPUT LEVEL +13dBu

Main & Aux RCA Outputs 1 - 4 (Unbalanced RCA)

• FREQUENCY RESPONSE 20Hz - 20kHz (+/-0.1dB)
• DYNAMIC RANGE 109dB (A-weighted)
• THD+N 0.003% (1kHz, -1dBFS)
• MAX OUTPUT +7dBu

Headphone Outputs (Stereo 1/4" TRS)

• DYNAMIC RANGE 101dB
• THD+N 0.008% (1kHz, -1dBFS, 36mW)
• MAX POWER 36mW (32-ohm load)
• MIN IMPEDANCE 32-ohm

What's In The Box

• AIR 192|8
• USB-C-to-USB-C Cable
• USB-C-to-USB-A Cable
• (2) 1/8" (3.5 mm) to MIDI Adapters
• Software Download Cards
• User Guide
• Safety and Warranty Manual
