Description

The Soundcraft Ui24R is a complete, rack-mountable, digital mixing and multi-track recording system that delivers flexible I/O, pristine sound quality, intuitive wireless control, and roadworthy reliability-all in a streamlined design. The system can double as a stagebox and can be controlled by up to 10 devices via Ethernet or built-in dual-band Wi-Fi, making it possible to control mixing and multi-track recording wirelessly from anywhere in the venue. With renowned HARMAN signal processing, Studer-designed preamps and much more-from the studio to the stage, Soundcraft Ui24R is the ultimate system for artists, venues and engineers who need to save space and deliver superior sound.

Ui24R brings together industry-leading HARMAN technologies to deliver unprecedented power and mission-critical stability. Renowned Studer preamps deliver rich sound for live performance and multi-track recording, while iconic Lexicon reverbs, choruses, delays, and dbx compression offer polished results for vocals, acoustic guitar and more. dbx AFS2 automatic feedback suppression is available on all monitor outputs, providing an excellent live experience. Plus, DigiTech guitar amp modeling brings a host of effects to any performance, particularly when low stage volume is desired.

When you need a mixer with comprehensive connections and a compact footprint, Ui24R provides the perfect, streamlined solution. The Ui24R allows you to mix from multiple sources including 10 combo 1/4"-TRS/XLR, 10 XLR, 2 line level inputs, and 2 channels of digital USB playback for a total of 24 channels. With its flexible and high-quality I/O, Ui24R gives venues, bands and engineers room to grow, with expanded creative options.

Control Ui24R from the device of your choice (tablet, phone, PC, Mac) via iOS, Android, Windows, Mac OS and Linux browsers, without installing apps. Onboard dual-band WiFi ensures you (and up to 9 members of the band) can always stay in control without relying on an independent router or the venue's WiFi. Musicians can adjust their individual mix on stage while the FOH engineer optimizes the audience experience.

Ui24R is more than just a complete mixing system-it's also a top-notch recording tool. Enjoy peace of mind with dual-path, multi-track recording of all 22 inputs and your stereo mix, directly to a USB storage drive AND a connected computer. The multi-channel USB audio interface also makes it easy to integrate the Ui24R into your recording studio for production work with your favorite DAW.

The Ableton Live 10 Lite software is an included download with all Ui Series mixers. Feed your creativity with this fast, flexible and sequencing workstation. From built-in instruments, sounds and effects to recording and mixing features, Live 10 Lite gives you everything you need to create, produce and perform.

Features:

• Renowned Soundcraft quality and performance
• Built-in dual-band Wi-Fi eliminates the need for a router to provides a reliable connection to up to 10 mobile devices in mission critical situations
• Control Ui24R from iOS, Android, Windows, Mac OS and Linux browsers without installing additional apps
• Record and mix with the warmth of 20 professional-quality Studer-designed preamps
• dbx compression and iconic Lexicon reverb and delay processing
• 2 channels of DigiTech guitar amp modeling
• Dual-path, redundant multi-track recording of all 24 inputs to USB drive and connected Mac/PC
• 24 simultaneous inputs (10 combo 1/4" TRS/XLR, 10 XLR, 2 line level, 2 digital)
• 4-band parametric EQ, high-pass filter, compressor, de-esser, and noise gate on input channels
• 31-band graphic EQ, noise gate, compressor, and dbx® AFS2 Automatic Feedback Suppression on all outputs
• Real-time frequency analyzer (RTA) on inputs and outputs
• Compatible with Mac/PC DAWs and other music software
• Compatible with Harman Connected PA application and system for easier setup and control
• 4U rackmount design

Specifications:

• Type: Digital Remote-controlled Mixer
• Channels: 24
• Inputs - Mic Preamps: 10 x XLR-1/4" combo, 10 x XLR
• Phantom Power: Yes
• Inputs - Line: 1 x stereo RCA
• Outputs - Main: 2 x XLR, 2 x 1/4"
• Busses/Groups: 8 x XLR (aux outs)
• Data I/O: 2 x Ethernet, 1 x HDMI
• USB: 4 x Type A, 1 x Type B
• Computer Connectivity: USB (24 x 24), Ethernet, Wi-Fi
• Headphones: 2 x 1/4"
• EQ Bands: 4-band parametric EQ, 31-band graphic EQ
• Effects: Lexicon Reverb, Lexicon Delay, DigitTech guitar amp modeling
• Signal Processing: dbx compression, dbx AFS2 auto feedback suppression, noise gate, de-esser
• Features: Built-in dual-band Wi-Fi, real time frequency analyzer, 24 track recording to USB
• Software: Remote control with iOS, Android, Windows, OS X and Linux
• Rackmountable: Yes (4U)
• Depth: 6.8"
• Width: 19"
• Weight: 22 lbs.
