JMAZ Lighting JZ3016 Phantom Beam 120 120W LED Moving Head

120w LED beam moving head light.

Features:

• 1 x 120W Cool White LED.
• 1 Color Wheel with 11 Colors Plus White.
• 19 Static Gobos Plus Open.
• 8+16-Facet Circular Prism with Variable Speed and Direction.
• DMX512, Master-slave, Sound Active, and Built-in Shows.
• Built-in Wireless DMX Technology.

Specifications

• Light Source: Source: 120W White LED

Color System:

• Color Wheel: 11 Colors + Open

Body:

• Hardware On-Board: sockets for quick-Lock Omega bracket
• Pan Angle: 630°
• Title Angle: 270°
• Pan/Tilt Resolution: 8 / 16 Bit
• Feedback: Scan position memory, auto reposition after unexpected movement
• Body: High Temperature Engineered Plastic and Cast Aluminum Casing
• Body Color: Black

Electronics:

• Dimmer: 0-100% Linear Dimmer

Electrical:

• Mains Power Supply:AC Mains
• Max Power Consumption: 180W
• Input Voltage: 110-240V, 50HZ/60HZ

Optics:

• Beam Angle: 2°

Dynamic Effect:

• Prism: 6 Facet Linear Prism, 8+16 Facet Circular Prism
• Gobos: 19 Static + Open

Control:

• Protocols: DMX512, W-DMX, Wi-MAZ Wireless DMX
• DMX Channels: 12/14 Channel Modes
• Wireless Control: Wi-MAZ Wireless DMX, W-DMX, RF Remote
• Firmware Upgrade: Yes, USB-DMX Interface, not included.

Physical:

• IP Rating: 20
• Cooling: Fan
• Pan/Tilt:8/16 bit smooth
• Data Connection: DMX, Wireless DMX
• Power Connection: Power-CON
• Dimensions: 13.2" x 8.8" x 19.4"
• Weight: 31.3 lbs

WHAT'S IN THE BOX

Each Phantom Beam 120 Retail Box Includes:

• (1) JMAZ Lighting JZ3016 Phantom Beam 120 120W LED Moving Head
• (1) User Manual
• (2) Omega Brackets
• (1) 3ft 3-pin DMX Cord
• (1) 3ft PowerCON Cord
• (1) RF Remote
