Highlights

• Compact moving head designed for large events
• Onboard USB-C port allows for quick software updates
• Built-in RF receiver for wireless control using the RFC or RFC-XL optional remotes
• New home position allows for smoother programming
• Dual rotating prisms split the beam for great effects and cover a larger area
• Motorized zoom for short or long throw applications
• ¼-turn hanging bracket allows for single or dual clamp mounting options
• Project crisp gobos from nearly any distance with the motorized focus
• Beams always remain on the dance floor using the built-in, innovative Totem mode
• Set, save, and recall 1 scene manually, directly from the full-color LCD display
• powerCON®-compatible power input/output connections saves setup time

Specifications

• DMX Channels: 10 or 16
• DMX Connectors: 3 XLR
• Pan and Tilt: 540°/270°
• Pan and Tilt Ranges: 540°, 360°, 180° pan/270°, 180°, 90° tilt
• Colors: 7 + white, split colors, continuous scroll at variable speeds
• Gobos: 7 + open (6 metal + 1 glass), rotating, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds
• Light Source: 1 LED (cool white) 250 W, (10 A), 50,000 hours life expectancy
• Strobe Rate: 0 to 20 Hz
• Lumens: 10,710
• Power Linking: 3 units @ 120 V; 7 units @ 230 V
• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power and Current: 378 W, 3.4 A @ 120 V, 60 Hz
  372 W, 1.9 A @ 230 V, 50 Hz
• Weight: 36.2 lb (16.5 kg)
• Size: 14.3 x 10 x 21 in (363 x 250 x 531 mm)
• Approvals: CE, UKCA, RoHS, MET
• Gobos: 8 + open, indexing, continuous scroll at variable speeds
• Gobo Size: 25.7 mm outside, 21 mm image, 1.3 mm max thickness
• Prism: 5-facet linear, bi-directional at variable speeds
• Prism: 6-facet round, bi-directional at variable speeds
• Zoom Angle (motorized): 13° to 28°
• Illuminance (13°) : 90,979 lux @ 2 m
• Illuminance (28°) : 24,565 lux @ 2 m
• Illuminance (13°) : 14,557 lux @ 5 m
• Illuminance (28°) : 3,930 lux @ 5 m
• Color Temperature: 15,000 K
• Optional Controllers: RFC, RFC-XL

WHAT'S INCLUDED

• Fixture
• Power cord
• Hanging bracket
• Quick Reference Guide
