Martin M-Touch 512 Channel DMX Lighting Controller

Description

Martin M-Touch is a powerful yet simple control surface for the Martin M-Series controllers, the most affordable professional lighting solutions on the market. Fully compatible with all M-Series consoles and M-PC software, Martin M-Touch is a plug-and-play solution with an innovative control surface like no other lighting console.

14 FSR faders allow control of playbacks and fixture parameters while 20 velocity-controlled pads allow for new types of effects. Additional programming buttons such as Record, Edit, Update, Load and Clear are accessible directly from the M-Touch control panel. Martin M-Touch comes with one DMX 512 Universe for direct control of any compatible DMX device.

Features:

Truly affordable console surface for both smaller applications and professional use
Rugged aluminum design for durability
The most powerful controller of its class with a full 512 DMX channels, expandable to 65,000 channels

Specifications

Control/User Interface

Bank Navigation Up/Down with numerical display
Main Go section: Snap, Release, Pause and Go buttons
Command Buttons: Record, Edit, Update, Load, Clear
Multifunction Mode Select button
Fixture Selection buttons: Last, Next, Highlight
4 x Parameter Select buttons
4 x Parameter Adjust touch faders
10 x Function velocity pads

Playback

10 x Playback touch faders with 3 buttons
(2 x touch pad, 1 x velocity pad)

System integration

Unlocks 1 x DMX universe when connected to M-PC

Construction

Housing: Aluminum, steel, plastic
Mounting: VESA 75x75, 100x100
Security: K-Lock locking slot
IP Rating: IP20

Connections

DMX data link: 1 x 5-pin locking XLR
Windows PC: USB 2.0

Electrical

Power source: 5 VDC over USB
Maximum current: 500 mA

Thermal

Operating temperature: 0° - 50° C (32° - 122° F)
Included Items
USB cable 1.5m (4.9 ft.)

Physical

Length: 394 mm (15.5 in.)
Width: 218.5 mm (8.6 in.)
Height: 46.5 mm (1.8 in.)
Weight: 1.5 kg (3.3 lbs.)

Physical

USB cable 1.5m (4.9 ft.)
