JBL VRX918SP

18 in. High Power Powered Flying Subwoofer

The VRX918SP is a powered, suspendable subwoofer system containing a 2268FF neodymium magnet, patented Differential Drive®, 18" woofer in a front-loaded, vented enclosure. The VRX918SP was designed specifically for use in arrays with the VRX932LAP Line Array speaker and VRX-AF Array Frame. In addition it may also be used in arrays consisting entirely of VRX918SP subwoofers.

Features

• Built-in JBL Drivepack® DPC-2 amplifier module designed by Crown provides 1500 Watts of peak Power. DSP based resident input module provides system optimization, EQ and crossover functionality.
• 18 inch, 2268FF dual voice coil, neodymium magnet Differential Drive® woofer for high-power capacity and light weight.
• Integral rigging hardware for simple connection of enclosures and optional array frame.
• 20 mm threaded pole socket for solid, secure satellite speaker mounting.
• Large port area for reduced distortion.

Specifications

• Power Rating 1500 Watts PeakLF: Dual-Bridged Technology™, Class D
• Frequency Range 31 Hz – 220 Hz
• Dimensions (H x W x D) 508 mm x 597 mm x 749 mm (20.0 in x 23.5 in x 29.5 in)
• Frequency Range (-10dB) 31 Hz – 220 Hz
• Maximum Peak Output 126 dB SPL at 1m
• Bandpass Nominal Impedance LF: 2 x 2 ohms
• LF Driver 1 x JBL 2268FF 457 mm (18 in) dual voice coil Differential Drive® woofer with neodymium-magnet
• Inputs XLR with loop through
• User Controls Input Attenuator (0-16 dB)Selectable 80 Hz or 120 Hz Low Pass 80 Hz High-Pass enable/disable for XLR loop thru.
• System Processing DSP based, resident in Input Module
• System Management DSP based limiters for mechanical and thermal protection
• AC Power Operating Range 90-132 VAC or 216-264 VAC, 50/60Hz
• AC Line Voltage User selectable: 120V/240V (-15%, +10%)
• AC Input Connector Neutrik PowerCon (NAC 3MPA)
• AC Loop Through Connector Neutrik PowerCon (NAC 3MPB)
• AC Current Requirements 6A per system at 120V, 3A per system at 240V
• Enclosure 18 mm birch plywood.
• Suspension / Mounting Optional VRX-AF line-array frame kit or 10 mm forged eyebolts
• Finish Black DuraFlex™ finish
• Grille Powder coated, black, 16-gauge perforated steel with acoustically transparent foam
• Net Weight (each) 38.5 kg (85 lb)
• Optional Accessories VRX-AF array frameSRX718S-CVR: Pull-over padded cover (works with WK-4S) SS4-BK adjustable satellite speaker pole WK-4S Caster kit
• Outputs 1 x XLR
• Nominal Impedance LF: 2 x 2 ohms
