Overview

The Gesture Beam 400 projects a crisp, tight beam for precise aerial effects and also offers a searchlight feature with stand alone sky-scanning mode. Four slave modes create complex auto programs without a DMX controller and the full color menu conveys all the essential information quickly and clearly.

Features

• 75W LED
• Motorized focus control via DMX or stand-alone menu
• 4 slave modes create complex auto programs without a DMX controller
• Manual selections enable pinspotting a cake or projecting a gobo without DMX controller
• Prism rotation & indexing get the perfect position every time
• Full-color menu: Easy-to-read, detailed menu system
• 1/4 turn mounting bracket included faster setup between shows
• Power Linking enables faster setup with fewer cables

specifications

• DMX Channels: 8 or 15
• DMX Connectors: 3-pin DMX in/out
• Pan and Tilt: 540°/270°
• Pan and Tilt Ranges: 540°, 360°, 180° pan/270°, 180°, 90° tilt
• Colors: 8 + white, split colors, scrolling
• Gobos: 8 + open, gobo shake & scrolling
• Gobo Size: 23.5 mm outside, 19 mm image, 1.1 mm max thickness
• Focus: Motorized + Frost
• Prism: 8 facet, with rotation and indexing
• Light Source: 75w White LED
• Beam Angle: 5°
• Illuminance: 81,400 lux @ 3M
• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-switching)
• Mounting: 1/4 turn, Omega Clamp Included
• Weight: 10.3KG/12.5KG - 22.7 lbs / 27.7 lbs
• Size: 21.8" x 17.5" x 12.4"
• Approvals: CE & FCC
• Strobe Rate: 0 to 20Hz + pulse and random
• Power Linking: 4pcs
• Power and Current: 96W, 12V 8A @ 230V, 50Hz - 108W, 36V 3A @ 230V, 50Hz
