Chauvet LFS-5

Chauvet LSF-5

LFS-5 is a compact, easy-to-use framing spot light powered by a 23-watt white LED. Utilizing a 16- to 24-degree zoom and internal framing shutters, you can easily size and mask light off unwanted surfaces with precision. A single gobo slot houses one of four included gobos, or a custom-made version. Nearly any color can be achieved with its removable gel frame.

Compact LED framing spot shines a hard-edged beam perfect for gobo projection
Highlight areas by altering the projected beam with framing shutters
Easily print your own gobos on transparency film
Flexibility to project from any distance using the 16°- 24° zoom range
Includes four popular gobos
Save time running extension cords by power linking multiple units
Transport your fixtures in the CHS-40 VIP Gear Bag
Gobo size: 25.4 mm outside, 19 mm image, 1 mm max thickness (size V)
Light source: 23 W (15.3 A) white LED 50,000 hrs
Zoom angle: 16°- 24°
Illuminance: 1,990 lux @ 2 m
Power linking: 23 units @ 120 V / 45 units @ 230 V
Input voltage: Auto-ranging 100-240 VAC 50/60 Hz
Power and current: 52 W, 0.4 A @ 120 V 60 Hz
Power and current: 56 W, 0.2 A @ 230 V 50 Hz
Weight: 3.2 lbs (1.5 kg)
Size: 12.7 x 8 x 9 in (325 x 205 x 229 mm)
PDF Manual

LFS-5
