PreSonus HP4 4-Channel Compact Headphone Amplifier

The HP4 from PreSonus answers the need for a headphone distribution amplifier with professional specifications in a small package at an affordable price. It is designed with four discrete headphone outputs on the front panel, each with its own volume potentiometer and 150mW of amplification per channel.

The HP4 also features adjustment capability for control-room monitors with a separate volume control, monitor mute switch and mono switch, thus giving you an extremely powerful monitoring solution at an amazingly low price.

Four High Power Headphone Outputs

The PreSonus HP4 manages four headphones with up to 150mW per channel. It features musical wide dynamic range, and control-room monitor outputs with level control.

Modular Add-On

This affordable unit can be added-on or added-to. The daisy chain configuration allows an infinite number of units to be connected.

Convenient Controls

There is no scrambling with this headphone distribution amplifier. With easy front-panel access you have push button mono or stereo operation, individual headphone level controls and a monitor mute switch right in front.

Specification

• Number of Channels 4
• Input Connections 1 x 1/4" TRS Input
• Output Connectors 4 x High Power 1/4" TRS Outputs
• Maximum Output Level -80dB to +10dB; 51 Ohm Impedance
• Function Controls Headphone Level, Monitor / Feed Output, Mono Switch, Monitor / Feed Mute
• Frequency Response 10Hz to 50kHz
• THD + N 0.002%
• Noise -98dB
• Display No
• Dimensions 5.5 x 1.75 x 5.5" (140 x 44 x 140mm)
• Weight 5 lbs (2.3kg)
• Package Weight 3.21 lb
• Box Dimensions (LxWxH) 12.5 x 7.85 x 4.25"
