SRM350 V2 Pack
SRM350V2 Pack

Inform me when this is back in stock
Email:
  • Two Mackie SRM350 V2 Speakers
    • 2-way bi-amplified, optimized Active loudspeaker system
    • High-output, titanium dome compression driver
    • 10-inch Neodymium long-throw low frequency transducer
    • 165-Watt class-D, Fast Recovery Low Frequency amp; 30-Watt High Frequency amp
    • Ultra-wide, smooth dispersion via HF waveguide
    • Built-in phase accurate 24dB Linkwitz-Riley electronic crossover
    • Electronic time correction, phase alignment and EQ for studio quality sound
    • Mic/line input and pass-thru connector
    • Lightweight for ultimate portability (26 lbs)
    • Flyable, Pole mountable, Floor wedge-able
      Specifications
    • Frequency Response (–3 dB): 83 Hz - 18.5 kHz
    • Frequency Range (–10 dB): 61 Hz - 22 kHz
    • Maximum SPL Long-Term @ 1m: 118 dB
    • Maximum SPL Peak @ 1m: 121 dB
    • Crossover: Linkwitz-Riley 24 dB/octave @ 2400 Hz
      Audio
    • Input Type: Balanced Differential
    • Input Impedance: 94k ohms
    • Sensitivity (center detent):
      - Line: +4 dBu
      - Mic: –36 dBu
    • Maximum Input Level: +22 dBu
    • Acoustic Contour Equalization (peaking):
      - +3 dB @ 100 Hz
      - +3 dB @ 12 kHz
    • Operating Temperature Range: –10ºC - 45ºC (14ºF - 113ºF)
      Power Amplifiers
    • Low-Frequency Power Amplifier:
      - Rated Power 165 watts continuous*
      - Rated THD < 0.03%
      - Cooling Convection Extrusion
      - Design Class D
    • High-Frequency Power Amplifier:
      - Rated Power 30 watts continuous*
      - Rated THD < 0.03%
      - Cooling Convection Extrusion
      - Design Class AB
    • Rated power is continuous rms wattage into transducer’s rated impedance @ 1 kHz for the HF amplifier and @ 100 Hz for the LF amplifier.
      Transducer Specifications
    • Low-Frequency Transducer:
      - Diameter: 10 inches (250 mm)
      - Voice Coil Diameter: 2.0 in (51 mm)
      - Sensitivity (1W@1m): 96 dB
      - Power Handling: 250 Watts RMS, long-term
      - Frequency Range: 61 Hz - 3 kHz
      - Magnet Type: Neodymium
    • High-Frequency Transducer:
      - Diaphragm Diameter: 1.4 in/36 mm
      - Horn Exit Diameter: 1 in/25.4 mm
      - Diaphragm Material: Titanium
      - Sensitivity (1W@1m): 104 dB
      - Nominal Impedance: 16 ohms
      - Power Handling: 75 Watts RMS, long-term
      - Frequency Range: 1 kHz - 20 kHz
      - Magnet Type: Ceramic
    • Horn Design:
      - Horizontal Coverage: 90º (1 kHz - 20 kHz)
      - Vertical Coverage: 80º (1 kHz - 20 kHz)
      - Mouth Size: 11.1 in x 6.1 in (283 mm x 154 mm)
      Enclosure Construction Features
    • Basic Design: Asymmetrical Trapezoidal
    • Material: Polypropylene
    • Finish: Midnight blue textured finish
    • Handles: One on side, one on top
    • Grille: Perforated metal with weather-resistant coating
      Line Input Power
    • Power Consumption: 120 watts with musical program and LIMIT LED blinking
    • US: 120 VAC, 60 Hz
    • Recommended Amperage Service: 2.5 amps
    • Note: The SRM350v2 does not support multiple voltage configurations.
      Control System Functions
    • Electronic Crossover
    • Phase Alignment
    • Equalization
    • Parametric Equalization
      Safety Features
    • Protection: Low-frequency Dynamic Bass Protection, Power Supply, and Amplifier Thermal Protection
    • Display LEDs: Signal, Power, Limit
      Physical Properties
    • Height 20.75 in (527 mm)
    • Width: 13.10 in (333 mm)
    • Depth: 12.25 in (311 mm)
    • Weight: 26 lbs. (11.8 kg)
      Mounting Methods
    • Optional hanging brackets for top and bottom of enclosure (SRM350 Bracket Kit: Part No. 0016404).
    • Never attempt to suspend the cabinet by its handles.
    • The SRM350 v2 is pole-mountable via the built-in socket on the bottom of the cabinet. Be sure the pole is capable of supporting the weight of the SRM350 v2.
  • Two Speaker Stands
  • FREE Speaker Cables!
