ELATION Platinum Profile 35 Pro Moving Head Effect Light

The Elation Platinum Profile 35 Pro (EPP409) is is part of the Elation Platinum Series and features the MSR Platinum 35, 800-watt lamp from Phillips, 16-bit resolution on all motor functions, 4 Blade Framing system w/ rotation, 2 gobo wheels with a total of 6 interchangeable, rotating, and indexing glass gobos, 3 fixed indexing gobos and a 160 animation effect, variable CMY color mixing and CTO, a static color wheel with 8 dichroic colors including UV and CTB, 3 facet rotating / indexing prism, frost filter, motorized focus / zoom system with an 8 to 50 beam angle, motorized 4 blade framing, pan/tilt lock, built-in EWDMX wireless DMX receiver, 3 and 5pin DMX connections, full color 180 reversible menu display with 6 button touch control panel, battery backup for display power, and a multi-voltage universal auto switching power supply (100-240v)

FEATURES
1200-Watt Comparable Lumens Output
Motorized 8° - 50° Zoom + 4 Blade Framing system w/ rotation
Built-In EWDMX Wireless DMX Receiver

SOURCE
Phillips™ 800-Watt MSR Platinum 35
750 Hour Average Life

PHOTOMETRIC DATA
20,101 Lumens, 7,400K, >60CRI
18,750 LUX @10M 8° Min Zoom
812 LUX @10M 50° Max Zoom

EFFECTS
4 Blade Framing system
160° Animation Effect
Frost Filter
3-Facet Prism and 16 Prism Macros
Strobe and 5% - 100% Iris
Mechanical Dimming: 0% - 100%

COLOR
Variable CMY Color Mixing & Variable CTO
8 Interchangeable Dichroic Colors Including UV + CTB

GOBOS
2 Gobo Wheels
6 Interchangeable / Rotating / Indexing Glass Gobos
3 Fixed / Indexing Gobos
Size: OD 29mm / ID 24mm

CONTROL / CONNECTIONS
3 DMX Channel Modes (37/39/60)
3pin & 5pin DMX In/Out
6 Button Touch Control Panel
Full Color 180° Reversible LCD Menu Display
8 / 16 Bit Resolution Adjustable Movement
powerCON Power In

SIZE / WEIGHT
Length: 19.9” (506.5mm)
Width: 17.6” (447.3mm)
Vertical Height: 28.6” (726.5mm)
Weight: 88.2 lbs. (40kg)

ELECTRICAL / THERMAL
AC 100-240V - 50/60Hz
1044W Max Power Consumption
-13°F to 113°F (-25°C to 45°C)

APPROVALS / RATINGS
CE Approved
cETLus Approved
IP20 Rated

INCLUDED ACCESSORIES
powerCON Cable
Safety Cable
3pin DMX Cable
