Great Amps, Super Efficient

The PPM1012 runs with Class D amps, which utilize power several times more efficiently than an A/B system, and run much cooler. They employ Mackie's excellent Fast Recovery circuitry as well. Unlike negative feedback power amps, which "latch" and dip the sound unpleasantly to avoid distortion, the Mackies instantly recover from clipping before latching is necessary. The result is a clean sound even at maximum output. The built-in limiter is one of Mackie's most celebrated contributions to powered speaker design, and the PPM1012 exemplifies this quality.

Super-Cool I/O Options

The PPM1012 is loaded with useful I/O. Notably, there are individual mono channel inserts included, so that you can easily use your favorite outboard compressor or digital FX processor on a signal of your choice. The mono channel inserts can also be used as all-purpose direct outs.

Onboard FX Deliciousness

Oh, by the way, this board has killer built-in FX! These are the Dual RMFX+ (Running Man FX) processors that deliver truly usable effects. Rather than long, endlessly scrolling menus with various options and parameters, the RMFX+ processor features 24 tried-and-true FX patches that offer broad usability. There are Small, Medium and Large Room Reverbs that can be tweaked between Warm and Bright settings. There are elegant choruses and straightforward and clean delays. Also, it has a tap function for the delay. Totally sweet!

Additionally, Channels 1-6 have dedicated in-line compressors that allow you to dial up great dynamic responses with the twist of a single knob.

Attractive and Highly Readable

The visual display on this mixer gives you a lot of information about your mix. Dual graphic EQs show the levels for both mains and monitors. High-resolution 12-segment main meters give you maximum information about your signal. Plus, the PPM1012 has 4-segment LEDs on every channel.

Features:

- Premium Mackie preamps on 8 mic/line channels
- Total of 8 mic/line mono inputs and 2 stereo line inputs
- True 48V phantom power on each channel
- Mackie's Musical 3-Band Active channel EQ
- Individual mono channel
- New Single In-line Compression (SIC) on Channels 1-6
- Dual graphic EQs for both mains and monitors
- 32-bit dual RMFX+ processor featuring 24 reverbs, choruses, and tap delay
- 12-segment LED level meters
- 2 x 9-Band graphic EQ on the Mains and Monitor outputs
- Mono output with level control & low pass filter selectable from 75Hz-100Hz
- 3-Mode Amplifier for switching between Mains Stereo L/R, Mono Mains/Monitor 1, or Mon 1 & Mon 2
- Headphone output with independent level control
- 12v BNC lamp Jack
- Rack ears included

Specifications

- Dual 800W Mackie designed Class-D, Fast Recovery power amplifiers
- 32-bit dual RMFX+ processor featuring 24 sane, useable reverbs, choruses, and tap delay for live applications
- 8 mic/line mono inputs and 2 stereo line inputs for flexible connectivity
- Mackie high-headroom, low-noise mic preamps with RF rejection for pristine signal
- Single In-line Compression (SIC) provides increased presence and punch for vocals and instruments
- Mackie's Musical 3-Band Active channel EQ with a Mid sweep (100Hz-8kHz) on mono channels & 4-band active EQ on stereo line channels 7 & 8
- 2 built-in DI boxes for direct instrument connections on channels 7 & 8
- 4 Aux sends-2 FX & 2 Mon
- 12-segment LED ladders for the stereo main outputs
- Dual 9-Band graphic EQ on the Mains and Monitor outputs for tuning rooms and monitor mixes
- Mono output with level control & low pass filter selectable from 75Hz-100Hz
- 3-Mode Amplifier for ultra-flexible routing, switchable as Mains Stereo L/R, Mono Mains/Monitor 1, or Mon 1 & Mon 2
- Precision Passive EQ for enhanced clarity and LF response with Mackie passive loudspeakers
- 48v Phantom power available for all mic inputs
- Headphone output with level control
- 12v BNC lamp Jack
- Metal chassis with a handle built into the front of the mixer for easy transport
- Rack ears included

Output at 8 ohms stereo: 250 watts per channel

Weight, Dimensions, and Manufacturer Part Numbers

• Shipping Weight: 36 lbs
• Shipping Dimensions: 24 x 23 x 11 in
• Manufacturer Part Number (MPN): 0026941-00
